Welcome to our industrial valve selection hub. As a reliable supplier, we provide detailed technical insights and high-grade products to meet your precise engineering requirements. If you are searching for accurate 10 inch cast iron wafer butterfly valve dimensions, complete flange compatibility, and competitive factory-direct pricing, you have come to the right place. Our 10" (DN250) cast iron wafer butterfly valves are engineered for exceptional flow control, easy installation, and long-lasting performance in water treatment, HVAC, and general industrial pipelines.
To assist engineers, contractors, and procurement managers in accurate pipeline designing, below is the standard technical dimensional overview for our 10-inch (DN250) cast iron wafer butterfly valves:
| Technical Parameter | Standard Specification (10 Inch / DN250) |
| Nominal Diameter | 10 Inch (DN250) |
| Face-to-Face Dimension (L) | ~68 mm (Complies with API 609 / ISO 5752) |
| Top Flange Dimension (ISO 5211) | F10 / F12 (Standard for actuator mounting) |
| Flange Accommodations | ANSI Class 125/150, PN10/PN16, JIS 10K |
| Body Material | Cast Iron (GG25 / HT200) / Ductile Iron (GGG40) |
| Disc Options | Ductile Iron (Nylon Coated), SS304, SS316, Al-Bronze |
| Seat Options | EPDM, NBR (Buna-N), PTFE, Viton |
| Working Pressure | PN10 / PN16 / 150 PSI |
(Note: Custom china 10 inch cast iron wafer butterfly valve dimensions and CAD/3D drawings are available upon request to fit non-standard piping configurations.)
Compact & Lightweight Structure
Designed according to global China 10 inch cast iron wafer butterfly valve dimensions, the thin face-to-face body drastically reduces system weight and simplifies handling compared to bulky gate or globe valves.
Universal Flange Compatibility
The wafer-style alignment holes ensure that our 10-inch valve aligns effortlessly between various standard pipe flanges worldwide, reducing installation time and installation errors.
Tight Bubble-Tight Sealing
Equipped with precision-molded resilient seats, our 10-inch butterfly valves achieve 100% bi-directional zero-leakage sealing, protecting system integrity under continuous cycling.
Multiple Operation Modes
Whether you require manual lever, worm gearboxes, or automated pneumatic/electric actuators, our top flange conforms strictly to ISO 5211 dimensions for fast actuator mounting.
Direct Manufacturer Advantages: We provide factory-direct pricing, fast production cycles, and complete OEM/ODM customization options for global valve distributors and contractors.
100% Quality Inspection: Every batch is tested for hydrostatic pressure, shell integrity, and precise 10 inch cast iron wafer butterfly valve dimensions prior to shipment, adhering to API 598 standards.
Complete Technical Support: Our engineering team provides instant CAD files, 3D models, and installation manuals to ensure seamless integration into your project drawings.
Need exact China 10 inch cast iron wafer butterfly valve dimensions for your engineering design or bulk procurement? Contact our technical sales team today for full datasheets, CAD files, and competitive wholesale quotes!
