In industrial fluid transmission and pipeline isolation, carbon steel butterfly valves are widely preferred for their exceptional structural strength, pressure endurance, and cost-efficiency. At FTJ Valves, as a leading China 6 inch carbon steel gear operated wafer butterfly valve dimensions manufacturer, we engineer robust, reliable, and high-performance flow control solutions designed for demanding applications such as oil & gas processing, power generation, HVAC systems, municipal water management, and heavy industrial plant construction.
Accurate fitting is essential to preventing pressure drops, leakage, and mechanical stress across your piping infrastructure. Finding exact 6 inch carbon steel gear operated wafer butterfly valve dimensions allows EPC contractors and piping engineers to design seamless system layouts.
Our 6-inch (DN150) wafer butterfly valves strictly follow global manufacturing and face-to-face standards, including API 609, ANSI B16.10, ISO 5752, and EN 558. The wafer-style body fits compactly between pipe flanges (compatible with ANSI Class 150/300, PN10, and PN16), minimizing overall installation weight and spatial footprint while offering rapid bolt-through installation.
Key Technical & Dimensional Specifications (6 Inch / DN150):
Nominal Diameter: 6 Inch / DN150
Body Material: High-grade Carbon Steel (WCB / ASTM A216)
Disc Options: Ductile Iron, Stainless Steel 304/316, or Nickel-Plated Carbon Steel
Actuation: Heavy-Duty Manual Worm Gearbox with Handwheel and Position Indicator
Seat Materials: EPDM, NBR, PTFE, or Metal-to-Metal Sealing for higher temperature tolerances
Pressure Rating: Class 150 / Class 300 / PN16 / PN25
Equipped with an enclosed, weatherproof worm gearbox, our 6-inch carbon steel wafer butterfly valve provides high torque multiplication. This mechanism ensures effortless, single-operator manual turning even under high differential pressures, eliminating fluid hammer and offering fine-tuned throttling capabilities.
Navigating international sourcing requires transparency, precise engineering support, and reliable quality assurance. As a primary hub for china 6 inch carbon steel gear operated wafer butterfly valve dimensions and valve manufacturing, FTJ Valves delivers direct factory-direct solutions backed by rigorous quality checks. Every valve undergoes 100% shell hydrostatic and seat leak testing in accordance with API 598 standard.
OEM & Custom Solutions: Custom face-to-face lengths, specialized epoxy coating colors, extended gear stems, and tailored seat materials.
Full Certification: CE, ISO9001 quality management, and MTR material certificates (EN 10204 3.1).
B2B Bulk Supply: Competitive factory pricing with flexible MOQ and global logistical support for distributors and engineering procurement teams.
Contact FTJ Valves today to download standard technical CAD drawings, request 3D models, or receive an immediate wholesale quote from our valve engineering specialists!
