Welcome to FTJ, your premier authority for industrial flow control and a leading China carbon steel wafer butterfly valve manufacturer. When specifying valves for high-pressure, high-temperature, or corrosive piping systems, accessing exact carbon steel wafer butterfly valve dimensions is critical for seamless installation, piping engineering, and long-term operational safety.
At FTJ, we manufacture high-performance carbon steel (WCB, LCC, WCC) wafer butterfly valves strictly following international face-to-face and flange connection standards, including API 609, ISO 5752, ASME B16.10, and EN 558.
Our engineering team provides full 2D and 3D CAD models, as well as comprehensive technical dimensional datasheets for all valve series. Below is an overview of our standard china carbon steel wafer butterfly valve dimensions:
Nominal Diameter Sizes: DN50 to DN1200 (2 inches to 48 inches)
Pressure Ratings: Class 150, Class 300, Class 600 / PN10, PN16, PN25, PN40
Face-to-Face Dimensions: Strictly aligned with API 609 Category A & B and EN 558 Series 20
Flange Accommodation: Universal wafer design compatible with ANSI B16.5, DIN 2501, and JIS 10K/16K flanges
Need customized face-to-face lengths or special shaft extension dimensions for insulated pipelines? Contact our technical support for custom-engineered dimensions.
Choosing the right carbon steel wafer butterfly valve dimensions goes beyond space planning; it directly impacts overall piping integrity:
High Structural Strength: Cast carbon steel (WCB) bodies provide superior pressure resistance and thermal stability compared to standard cast iron valves.
Compact & Lightweight Space Saving: The short face-to-face wafer dimension minimizes pipe footprint, reduces installation weight, and lowers overall shipping costs.
Versatile Sealing Options: Available in concentric, double-offset (high performance), and triple-offset designs with PTFE, RPTFE, or metal-to-metal seating for zero-leakage shutoff.
Multiple Operation Modes: Compatible with manual lever, worm gear, electric actuator, or pneumatic actuator mounting pads (ISO 5211 top flange dimensions).
Whether you are an EPC contractor, valve distributor, or system integrator, FTJ offers complete customization beyond standard China carbon steel wafer butterfly valve dimensions. We provide:
Full material certification (EN 10204 3.1) and strict 100% pressure hydrostatic testing.
Custom coating thickness, stem extensions, and specialized trim materials (SS316, Monel, Duplex).
Direct factory pricing with robust export packaging to ensure safe delivery worldwide.
