China Swing Check Valve Stainless Steel 10 Inch Dimensions

Standard China Swing Check Valve Stainless Steel 10 Inch Dimensions & Technical Specifications

When designing or maintaining large-scale fluid systems, obtaining accurate physical dimensions and flange drilling specs is essential for flawless piping installation. If you are looking for precise details regarding china swing check valve stainless steel 10 inch dimensions, FTJ Valves offers comprehensive manufacturing standards and factory-direct engineering support for international EPC projects and industrial buyers.

Our 10-inch (DN250) stainless steel swing check valves are engineered to prevent backflow automatically, safeguarding pumps, compressors, and pipeline infrastructure. Manufactured using premium cast stainless steel (ASTM A351 CF8 / CF8M / SS316), these non-return valves deliver exceptional structural integrity and superior corrosion resistance under severe media and high-pressure conditions.

General 10 Inch Stainless Steel Swing Check Valve Dimensional Reference

To assist project engineers and procurement teams in layout planning, our standard 10-inch flanged swing check valves strictly adhere to international face-to-face and flange connection standards:

• Nominal Size: 10 Inch / DN250
• Design & Manufacture Standard: API 6D, ASME B16.34, or BS 1868
• Face-to-Face Dimensions (L): Conforms to ASME B16.10 (Class 150 RF: approx. 622 mm / 24.5 in; Class 300 RF: approx. 711 mm / 28 in)
• Flange Dimensions & Drilling: Complies with ASME B16.5 (ANSI 150#, 300#, or PN16/PN40 per EN 1092-1)
• Top Bonnet Height (H) & Hand Clearance: Designed for compact space integration with a bolted cover for easy inline maintenance.

*Note: Custom face-to-face measurements, butt-weld ends (ASME B16.25), and special drillings are available upon request to match your exact jobsite replacement requirements.

Key Performance Characteristics & Material Benefits

Engineered for high flow efficiency and low pressure drop, every swing check valve stainless steel 10 inch dimensions design built by FTJ Valves features:

• Full Port Flow Design: Ensures maximum throughput and minimizes turbulence, reducing total operational energy costs across pumping stations.
• Heavy-Duty SS316 / CF8M Disc: Provides a tight, bi-directional seal and long service life in aggressive chemical, brine, and wastewater environments.
• Leak-Free Bolted Cover Construction: Equipped with spiral wound stainless steel gaskets to prevent external leakage under pressure surges.

Why Work directly with FTJ Valves in China?

As a specialized valve manufacturer, FTJ Valves simplifies global procurement. Beyond providing detailed CAD drawings and accurate China swing check valve stainless steel 10 inch dimensions, we execute 100% shell and seat pressure testing according to API 598 prior to shipment. We supply full EN10204 3.1 material test certificates (MTC), competitive wholesale pricing, and fast production lead times for distributors and contractors worldwide.
